Machining Equipment
Advanced machining equipment provides high precision and productivity when manufacturing complex components, while cutting-edge automation and high-speed processing technologies ensure consistent quality and efficient production.
VARIAXIS 730 5X II
| Travel Distance | 730x850x560(mm) |
|---|---|
| Table Size | 630x500(mm) |
INTEGREX 200IV T
| Travel Distance | 580x160x1,045 (mm), 225° |
|---|---|
| Chuck Size | 8" |
STUDER S21
| Center Height | 125mm |
|---|---|
| X-Axis Travel Distance | 400mm |
MYNX 6500
| Center Height | 1,270x670x625 (mm) |
|---|---|
| Table Size | 1,400x670 (mm) |
PUMA 3100 ULM
| Chuck Size | 12" |
|---|---|
| Machining Length | 3,125mm |
L300MA
| Chuck Size | 10" |
|---|---|
| Maximum Machining Length | 680mm |
Measurement Equipment
Precision measuring equipment accurately analyzes even the slightest deviations using advanced digital and non-contact technologies, and ensures fast and reliable quality verification through data transmission and automation functions.
ZEISS CONTURA G2 (3D Measurement Device)
| Measurement Range | 1,000x1,600x600 (mm) |
|---|
S4D3000-D (Surface and Shape Measurement Device)
| Max Drive | 200mm |
|---|---|
| Detection Range | 60mm |
Pitch Measurement Device (Nut)
| For measuring ball screw nut thread pitch |
Pitch Measurement Device (Shaft)
| For measuring ball screw shaft thread pitch |
Micro Hite M 600(2D Measurement Device)
| Measurement Range | 1,600mm |
|---|
